DMX512 Control Good Color Mixing LED COB Stage Par light 60W RGBW
Product Details:
Place of Origin: | China |
Brand Name: | Intuiit |
Certification: | CE&Rohs |
Model Number: | MYLED-056C |
Payment & Shipping Terms:
Minimum Order Quantity: | 50pcs |
---|---|
Packaging Details: | Carton、flight case |
Delivery Time: | 30~35 days |
Payment Terms: | T/T |
Supply Ability: | 10000pcs/month |
Detail Information |
|||
Type: | Stage Par Light | Light Source: | LED |
---|---|---|---|
Lamp Power: | 60W | Input Voltage: | AC100V-240V |
IP Rate: | IP20 | Warranty: | 1-year |
Product Description
MYLED-056C
DMX512 Control Good Color Mixing LED COB Stage Par light 60W RGBW
MYLED-056C is a 60W RGBW COB stage par light. There are RGB, WW, CW, UV led types optional
With both 3pin&5pin DMX in&out, Seetronic power con in&out, it is the product which is more for professional stage or event.
The Beam angle is 90degree reflector cup. Customers could choose to add a Fresnel len then could change the beam angle to 35degree. Consider the brightness, it is better to use the item within 5 meter distance.
It include the rich modes like master/slave, sound, built-in problem, auto running, DMX. The very good performance would earn a lot of benefit for the users.
Specification
Item number | MYLED-056C | |||||
Product Dimension | 279*330*162mm | |||||
Inner box | 315*240*390 mm | |||||
Outer box | 655*505*350mm(4pcs/ctn) | |||||
Weight | N.W 3.8kg /G.W 5.2kg | |||||
Connector | DMX in/out,power in/out | |||||
Power Voltage | AC100V ~ 240V,60/50Hz | |||||
Power Consumption | 63W | 60W@110V | 63W@240V | Power factor | 0.65 | |
Power linking | 8pcs@110V | 14pcs@240V | ||||
LED | 4-IN-1 RGBW | |||||
Dimming | 0-100%(13-bit) | Strobe | 0-20Hz | |||
Beam angle | 120degree | |||||
DMX channel | 3,6,7CHs | |||||
IP | IP20 | |||||
Working Tempreture | -20 ~ +45℃ |
Dimension sheet:
Effect image:
FAQ
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable
Q2. What about the lead time?
A:Sample needs 5~15 days, mass production time needs 25~35days
Q3. Do you have any MOQ limit for led light order?
A: MOQ20 to 50, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A:Firstly:let us know your requirements or application.
Secondly:We quote according to your requirements or our suggestions.
Thirdly:customer confirms the samples and places deposit for formal order.
Fourthly:We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 1, 2 , 5 year warranty to our products.
Q8: How to deal with the faulth?
A: Firstly:Our products are produced in strict quality control system and the defective rate will be less than 2%.
Secondly:during the guarantee period, we will send new spare parts for replacement. For defective batch products, we can discuss with the real situation.
Q9: Do you work a project?
A: Sure. We have more than 50 engineers and a EPC department. We are a national high-tech enterprise which integrates with " Lighting Design, Product R&D and manufacturing, control & programming, installation, Maintenance and upgrading".
