DMX Waterproof IP65 Outdoor RGBW Wall Washer LED Linear Facade Lights For Landscape Building Outline Lighting
Product Details:
| Place of Origin: | China |
| Brand Name: | Intuiit |
| Certification: | CE,RoSH |
| Model Number: | IXQ17D |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100ocs |
|---|---|
| Packaging Details: | Carton |
| Delivery Time: | 25-35days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10000pcs/Months |
|
Detail Information |
|||
| Type: | Led Wall Washer Light | Light Source: | LED |
|---|---|---|---|
| Lamp Power: | 60W | Input Voltage: | DC24V |
| IP Rated: | IP65 | Warranty: | 2 Years |
| High Light: | IP65 Outdoor RGBW Wall Washer,Waterproof RGBW Wall Washer,DMX LED Linear Facade Lights |
||
Product Description
Aluminum waterproof dmx exterior color change dc24V rgbw 4 in 1 led wall washer light
DMX Waterproof IP65 Outdoor RGBW Wall Washer LED Linear Facade Lights For Landscape Building Outline Lighting
We have the length of 1m, 0.5m.0.3m optional for project use
The fixture is configurated superior optical system.
It also have rich angles for different application.
DMX512 protocol and RDM function
Color change is natural, with better color mixing, meanwhile,
it also have single white LED type opprotidoun.
This fixture can be widely used in theme park,t heme town, high buildings,
live show , bridge, pier, high tower lighting and other places
Specification:
| Item Number | IXT18C20(1000mm) IXT18C21(500mm) IXT87C22(300mm) |
IXT18C02(1000mm) IXT18C36(500mm) IXT87C37(300mm) |
IXT18C04(1000mm) IXT18C34(500mm) IXT87C35(300mm) |
IXT18C38(1000mm)
IXT18C32(500mm) IXT87C33(300mm) |
|
| LED Qty | 48 pcs(1000mm)/24 pcs(500mm)/12 pcs(300mm) | ||||
| Beam Angle | 110 ° | ||||
| Spot Angle | 160 ° | ||||
| Lumen | 755lm/460lm/220lm | 410lm/200lm/150lm | 440lm/215lm/160lm | ||
| CRI | Ra≥70 | / | / | ||
| Color Tempreture | 1800K∽6000K optional | RGB | RGBW(W:3000/4000/6000K optional | ||
| Product Measurement | 1000x45x46mm(1000mm)/500x45x46mm(500mm)/300x45x46mm(300mm) | ||||
| N.W. | 0.8kg(1000mm)/0.5kg(500mm)/0.3kg(300mm) | ||||
| Input Voltage Range | DC24V | ||||
| Watts | 12W(1000mm)/6W(500mm)/3W(300mm) | ||||
| Power Factor | ＞0.9 | ||||
| Housing Material | Tensile Aluminum | ||||
| Color | Matt black / Grey | ||||
| Cooling | Natural convection cooling | ||||
| Control Protocol | ON/OFF | DMX512 | DMX512 | DMX512 | |
| Segmented Control | / | 8 Section(1000mm)/4 Section(500mm)/2 Section(300mm) | |||
| Channel | / | ||||
| Power /Installation | Independent | ||||
| Conection | 2pin rubber cable:input/output | black rubber cable 5 Pin In & Out | |||
| Power Linking | 8pcs(1000mm)/16pcs(500mm)/32pcs(300mm) | ||||
| DMX Linking | / | 16pcs(1000mm)/32pcs(500mm)/64pcs(300mm) | |||
| Certification | CE,RoHS | ||||
| IP Grade | IP65 | ||||
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable
Q2. What about the lead time?
A: Sample needs 5~15 days, mass production time needs 25~35days
Q3. Do you have any MOQ limit for led light order?
A: MOQ20 to 50, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly:let us know your requirements or application.
Secondly:We quote according to your requirements or our suggestions.
Thirdly:customer confirms the samples and places deposit for formal order.
Fourthly:We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 1, 2 , 5 year warranty to our products.
Q8: How to deal with the faulth?
A: Firstly:Our products are produced in strict quality control system and the defective rate will be less than 2%.
Secondly:during the guarantee period, we will send new spare parts for replacement. For defective batch products, we can discuss with the real situation.
Q9: Do you work a project?
A: Sure. We have more than 50 engineers and a EPC department. We are a national high-tech enterprise which integrates with " Lighting Design, Product R&D and manufacturing, control & programming, installation, Mainte
