High Quality Stage Led Par Pixel Lights 15*10w Rgbwa+uv Stage Lamp Par Led Light
Product Details:
| Place of Origin: | China |
| Brand Name: | Intuiit |
| Certification: | CE&RoHS |
| Model Number: | CT-021P-6C |
Payment & Shipping Terms:
| Minimum Order Quantity: | negotiated |
|---|---|
| Packaging Details: | Inner box+ Master Carton, Flight case |
| Delivery Time: | 25-35days for mass order |
| Payment Terms: | T/T IN ADVANCE |
| Supply Ability: | 10000Pcs/Month |
|
Detail Information |
|||
| LED Qty: | 15pcs*10W 6-in-1 RGBWA-UV | CCT: | 1800K~8000K |
|---|---|---|---|
| Lumen: | 2455lm | Beam Angle: | 20*30° |
| Input Voltage: | AC100~240V, 50-60Hz | IP Grade: | IP65 |
| DMX Channels: | 6CH、8CH、12CH 、90CH、96CH | Product's Dimension: | 999x145x153mm |
| N.W: | 7KG | Control: | DMX-RDM |
| High Light: | Rgbwa+uv par pixel lights,15*10w par pixel lights |
||
Product Description
The CT-021-6C is a powerful IP65-rated LED pixel bar designed for professional stage lighting. It features 15x 10-watt RGBWA-UV LEDs with individually controllable pixels, providing precise control over lighting effects.
With a 33° fixed horizontal and 22° vertical beam angle, the CT-021-6C offers wide coverage for stage lighting. It includes a 0-100% dimmer and 0-15 Hz strobe effects, making it ideal for color mixing and dynamic light displays.
Control options for the CT-021-6C include manual operation, DMX control, IR remote control, and Master/Slave mode. It supports both manual and auto run modes with built-in programs. The unit is equipped with Seetronic Power Pro True IP65-rated connectors, ensuring reliable power connections and compatibility with leading brands.
Overall, the CT-021-6C is a versatile and reliable LED pixel bar that meets the demands of professional stage lighting. Its waterproof design, powerful output, and flexible control options make it a valuable tool for lighting designers and stage professionals.
Technical Data
| LED Qty | 15pcs*10W 6-in-1 RGBALC |
| 15pcs*10W 6-in-1 RGBWA-UV | |
| CCT | 1800K~8000K |
| Lumen | 2455lm |
| Beam angle | 20*30° |
| Input voltage | AC100~240V, 50-60Hz |
| Power | 128W |
| Drive current | 500mA |
| Dimming | 16Bit |
| IP Grade | IP65 |
| Cooling | Natural convection cooling |
| Control protocol | DMX512 ,RDM |
FAQ
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable
Q2. What about the lead time?
A: Sample needs 5~15 days, mass production time needs 25~35days
Q3. Do you have any MOQ limit for led light order?
A: MOQ20 to 50, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly:let us know your requirements or application.
Secondly:We quote according to your requirements or our suggestions.
Thirdly:customer confirms the samples and places deposit for formal order.
Fourthly:We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 1, 2 , 5 year warranty to our products.
Q8: How to deal with the faulth?
A: Firstly:Our products are produced in strict quality control system and the defective rate will be less than 2%.
Secondly:during the guarantee period, we will send new spare parts for replacement. For defective batch products, we can discuss with the real situation.
Q9: Do you work a project?
A: Sure. We have more than 50 engineers and a EPC department. We are a national high-tech enterprise which integrates with " Lighting Design, Product R&D and manufacturing, control & programming, installation, Maintenance and upgrading".
